IPFX (MTP/MO)
ODVA (MTP/MPO)
Hoog - dichtheid
|
Prestatieniveau
|
|
|
Norm
|
|
Elite
|
|
||||
|
Schakelaar
|
Wijze
|
Endface
|
(Maximum) IL (dB)
|
RL (min) (dB)
|
(Maximum) IL (dB)
|
RL (min) (dB)
|
||||
|
MPO/MTP
|
SM
|
12F/APC
|
≤0.70
|
≥60
|
≤0.35
|
≥60
|
||||
|
|
|
24F/APC
|
≤0.75
|
≥60
|
≤0.35
|
≥60
|
||||
|
|
|
48F/APC
|
≤0.75
|
≥60
|
|
|
||||
|
|
MM.
|
12F/PC
|
≤0.50
|
≥20
|
≤0.35
|
≥20
|
||||
|
|
|
24F/PC
|
≤0.50
|
≥20
|
≤0.35
|
≥20
|
||||
|
|
|
48F/PC
|
≤0.50
|
≥20
|
|
|
||||
|
LC/SC/FC/ST
|
SM
|
|
≤0.30
|
≥60
|
≤0.10
|
≥60
|
||||
|
|
|
UPC
|
≤0.20
|
≥50
|
≤0.10
|
≥50
|
||||
|
|
MM.
|
PC
|
≤0.20
|
≥30
|
≤0.10
|
≥30
|
||||
Nota:
1.Test golflengte: SM@1310/1550nm, MM@850/1300nm;
2.Standard conformiteit: GR.-326, GR.-1435.
|
Mechanische Eigenschappen
|
|
|
|
|||
|
Punt
|
|
Criteria
|
Conformiteit
|
|||
|
△IL na 50 Matings
|
MPO/MTP
|
≤0.3dB
|
Gr.-1435
|
|||
|
△IL na 500 Matings
|
LC/SC/FC/ST
|
≤0.2dB
|
CEI 61300-2-2
|
|||
|
(Dynamisch) Min Bend Radius
|
|
20*OD (Kabeldiameter)
|
|
|||
|
(Statisch) Min Bend Radius
|
|
15*OD (Kabeldiameter)
|
|
|||
|
Milieuvoorwaarden
|
|
|
|
|||
|
Punt
|
Criteria
|
Conformiteit
|
|
|||
|
Verrichtingstemperatuur
|
-40~60°C
|
CEI 61753-1
|
|
|||
|
Opslagtemperatuur
|
-45~85°C
|
|
|
|||
